Rotary Unions

The 200 Series single passage rotary unions are compact and corrosion-resistant featuring Carbon Steel with Electroless Nickel Plating body. These are widely used in high pressure Oil/Water applications. All 200 series rotary union come standard with a male threaded shaft and female threaded housing for easy mounting.

• Media Type: Water/Oil/Air/Vacuum
• Connection Types: British Standard Pipe Thread (BSP); other thread sizes available on request
• Body Material Type: Carbon Steel with corrosion resistance ENP plating *SS304 or SS316 body material available on request
• Max Operating Pressure: 150 Bar
• Max Rotational Speed: 100 RPM
• Operating Temperature: -18 to 90 deg Celsius *(Upto 250 deg C available on request) Kindly confirm while ordering
• Below prices are given in standard specifications *Customizations in body material and operating temperature possible and price will increase. Kindly contact for customizations


• Available Passage Size in type inline inlet/outlet passages:


• Kindly contact us for estimating delivery time or shipping charges
200 series rotary union

• Drawings provided above are based on our best knowledge. Minor updates in drawing might not be reflected on website. Buyers are requested to confirm the drawing while order placement.
